Electric counterbalanced reach truck is a warehouse forklift truck, is a kind of material handling equipment, refers to the loading and unloading of pallet goods, stacking and short distance transportation operations of the forward handling vehicle, usually used for the transportation of large storage objects, the use of battery driven. The electric reach forklift has the characteristics of flexibility, light operation, no pollution, low noise, etc. It combines the advantages of electric pallet stacker and electric counterbalanced forklift. When the door frame reaches the top, the center of gravity of load falls on the outside of the fulcrum, this is equivalent to the counterweight forklift truck; When the door frame is fully recovered, the center of gravity of the load falls on the inside of the fulcrum, which is equivalent to an electric stroller. The combination of these two properties makes it possible to ensure the flexibility of operation and high load performance at the same time, the volume and self-weight will not increase a lot, maximize the saving of working space, and greatly improve the utilization of space. Therefore, it is suitable for the narrow space of light industry, tobacco, textile, food, supermarket and other industries to complete material handling and stacking operations, and is one of the essential equipment for modern warehousing.

Advantages:

1. Strong balance: The electric balanced heavy forward vehicle adopts the design of the center of gravity forward, which effectively increases the weight of the front by placing the battery or other weight components on the front of the vehicle, improving the stability and balance of the vehicle. This makes the vehicle more stable and less prone to tipping during driving, providing a safer and more reliable travel experience.

2. Flexible handling: Due to the forward shift of the center of gravity, the vehicle's weight tilts forward, which can increase the grip of the front wheels and improve the turning flexibility and handling of the vehicle. The user can easily control the steering and speed of the vehicle by shifting the center of gravity of the body to achieve intuitive handling effects.

3. Both speed and distance: Electric counterweight forward vehicles usually use a powerful electric drive system, which can provide higher speed and longer driving range. This makes the vehicle suitable for a variety of travel scenarios, including daily commutes, excursions and city excursions.

4. Environmental protection and energy saving: As an electric vehicle, the electric balanced weight forward vehicle has no emissions, low noise, and uses electric energy as a power source, which has lower environmental impact compared with traditional fuel vehicles. The use of electric balanced weight vehicles can reduce air pollution and noise pollution, helping to protect the environment and improve urban air quality.

5. Electric drive: The electric counterweight forward vehicle uses an electric drive system to drive the vehicle forward through battery power supply. This electric drive allows the vehicle to achieve zero emissions, is more environmentally friendly, and is more suitable for urban environments.

6. Environmental adaptability: Electric counterweight vehicles usually have a small size and lightweight design, making them suitable for narrow roads, sidewalks and indoor Spaces. They usually have a small turning radius, making it easy to turn and move in narrow areas.

Operation Skills:

1. Press the accelerator pedal before opening the key switch, otherwise the forklift will have a fault code and the forklift will not run;

2. Switch the reversing lever to the opposite direction when the forklift is running, then the electrical brake will work, and the forklift will slow down and stop and slowly run in the other direction;

3. The steering system of this kind of electric forklift truck is full hydraulic steering. When the oil pump motor stops working, the steering will be very difficult, and the oil pump motor must be started to achieve the steering easily;

4. Do not press the accelerator pedal and brake pedal at the same time;

5. When used, no excessive discharge and timely charging, long-term shelving should also be replenished once a week;

6. Do not regularly check the liquid level of the electric forklift battery, if it is lower than the calibration line, the distilled water should be added in time, do not add tap water, river water, mineral water, so as to avoid mixing the battery internal self-discharge failure caused by mixed antagonism, do not add electrolytic hydraulic pressure, otherwise it will increase the electrolyte concentration and shorten the battery life;

7. Special attention should be paid to the timely charging of the battery and the correct maintenance of the battery in the use of the forward lift truck. When charging the battery, pay attention to the method, which should not only make the battery fully charged, but also cause the battery to overcharge;

8. In the operation of the forward forklift truck, try to use a long distance acceleration as little as possible. When the vehicle starts and the speed increases, hold the accelerator pedal steady. When the vehicle needs to slow down, relax the accelerator pedal and gently step on the brake pedal, so that the energy of deceleration can be fully utilized. If the vehicle has regenerative braking function, the kinetic energy of deceleration can be recovered. When the vehicle is going down the ramp, do not disconnect the circuit of the driving motor, and gently press the brake pedal to make the vehicle run in the regenerative braking state, and use the kinetic energy of the vehicle to reduce the energy consumption of the battery;

9. During the operation of the vehicle, do not mistake the direction switch of "forward and backward" as the steering switch. Unless an emergency deceleration is required, do not press the brake pedal directly to the end. During the use of the vehicle, when the battery is found to be insufficient (which can be obtained through the electricity meter, power deficit indicator light and other alarm devices), the battery should be charged as soon as possible to prevent excessive discharge of the battery.
